Form Builder Addon

The add-on works with MEC version 4.2.3 and higher.

The Form Builder is a new add-on for MEC which employs Elementor Page Builder.
It allows you to style the tickets’ booking form however you want. In order to use Form Builder you need to have MEC Pro and Elementor Page Builder installed and activated.

For installation, first, make sure that both MEC and Elementor Page Builder are installed and activated. Then, head over to your WordPress Dashboard > Plugins > Add New and upload, install, and activate the add-on

Form Builder - WordPress Event Calendar

In order to create your first form, please go to MEC > Form Builder and click on Add New With Elementor.

The first time, the page is blank.

Form Builder - WordPress Event Calendar

Choose your title and then click “Edit With Elementor.”

Form Builder - WordPress Event Calendar

You will then be redirected to Elementor Page Builder. Then find “MEC Form Builder” and place it in one of the sections.

Form Builder - WordPress Event Calendar

Click “Add Item”, and add fields to the form. Then you can set the field type for this particular field.

Form Builder - WordPress Event Calendar

There’s also another option with which you can divide the width of the field to half. To do this, simply enable “Half-Width” option. The other option is “Required Field” by which you can make a field necessary for proceeding. Also, you can rearrange the fields by dragging and dropping them.

MEC Form Builder - WordPress Event Calendar

Go to the Style tab, and blend the style of your form with the style of your website.

MEC Form Builder - WordPress Event Calendar

Now you can publish the form. Head over to the dashboard and enable this form for your desired event (https://webnus.net/dox/modern-events-calendar/add-a-booking-system/ ).

In order to enable the form in the back-end of an event with ticket, you need to uncheck the box for “Inherit from global options” in MEC Settings > Booking Form.

Form Builder - WordPress Event Calendar

Now you have two options to choose your form. You can use the traditional method and create your form in MEC Settings > Booking Form which has the default style or by choosing “Elementor Form Builder,” you can select your desired form which you created before; by simply selecting it from the drop-down menu.

Form Builder - WordPress Event Calendar

Now update your event or publish it if you just created it and then click View Event. Click the register button to be redirected to the booking section or have booking module pop-up open.

Form Builder - WordPress Event Calendar

Complete the purchase, and then the form you have created will be available there.

Form Builder - WordPress Event Calendar

For the file’s fields, you need to make some adjustments.

1. You can set certain limits for uploading files from MEC Settings > Upload Field. These limits include the size of the file or its format.

2. The size for the file to upload is set by the php.ini file which is the file handling your site’s server. : upload_max_filesize on php.ini file. For more information please contact your host provider.
